Model
|
IPC3611SR3-PF36
|
|
Camera
|
|
Sensor
|
1/3", 1.3 megapixel, progressive scan CMOS
|
|
Shutter
|
Otomatik/Manuel, 1/6~1/8000 s
|
|
Lens
|
2.8mm@F1.8(3.6mm, 6mm optional)
Angle of view(H): 99.1° (76.7° / 46.9°)
|
|
Min. Illumination
|
Colour: 0.02 Lux (F2.0, AGC ON) 0 Lux with IR
|
|
Day/Night
|
IR-cut filter with auto switch (ICR)
|
|
IR Range
|
30m (98 ft) IR range
|
|
S/N
|
50dB den fazla
|
|
WDR
|
Digital
|
|
Video
|
|
Max. Resolution
|
1280 × 960
|
|
Video Compression
|
U-Code/H.264, MJPEG
|
|
Frame Rate
|
960P (1280*960): Max. 30 fps;
|
| 720P (1280×720): Max. 30 fps; D1 (720×576): Max. 25 fps |
|
9:16 Corridor Mode
|
Destekler
|
|
ROI
|
Destekler
|
|
Video Streaming
|
Triple
|
|
OSD
|
Destekler
|
|
Privacy Mask
|
Destekler
|
|
Smart
|
|
Behavior Detection
|
N/A
|
|
Exception Detection
|
N/A
|
|
Intelligent Identification
|
N/A
|
|
Statistical Analysis
|
N/A
|
|
Audio
|
|
Audio Compression
|
N/A
|
|
Two-way audio
|
N/A
|
|
Storage
|
|
Edge Storage
|
N/A
|
|
Network
|
|
Protocols
|
IPv4,IPv6,IGMP,ICMP,ARP,TCP,UDP,DHCP,RTP,RTSP,Qos,DNS,DDNS,NTP,FTP,UPnP,HTTP
|
|
Compatible Integration
|
ONVIF
|
|
Interface
|
|
Audio I/O
|
N/A
|
|
N/A
|
|
N/A
|
|
Alarm I/O
|
N/A
|
|
Network
|
10M/100M Base-TX Ethernet
|
|
General
|
|
Power
|
12 V DC, or PoE (IEEE802.3 af)
|
|
Power consumption: 3.5 W (5.5W with IR on)
|
|
Material
|
N/A |
|
Dimensions (L × W × H)
|
Φ126 x 94 mm (Ø5.0" x 3.7")
|
|
Weight
|
0.33 kg
|
|
Working Environment
|
-35°C ~ +60°C (-31°F ~ 140°F), Humidity ≤ 90% RH(non-condensing)
|
|
Vandal Resistant
|
N/A
|
|
Ingress Protection
|
IP66
|
